The eight pieces of die sets are in the same level with same sizes, to ensure the crimped hose assembly elegant and sturdy.
Imported sealing elements, to ensure the head with good tightness
Electronic control opening, more convenient to use
Die sets to be changed in axis position, suitable for non-standard pipeline
Technical data
Crimping range
1/8”-2 1/2”
Standard voltage and motor
380V/4kW
Opening without dies
Φ134mm
Opening
≥28mm
Weight
326Kg
No. of standard die
11 sets
Systematic pressure
30MPa
